The Male 90° Elbow Quick Connect (3/8" Tube x 3/8" NPT) is a high-utility fitting used for creating secure and space-efficient connections in pneumatic and fluid systems. Below is a detailed overview:
Key Specifications:-
· Configuration:
o 90° Elbow: Designed to make a right-angle connection.
o Quick Connect (Push-to-Connect): Ensures easy and reliable tubing installation.
· Connection Ends:
o 3/8" Tube: Push-to-connect fitting for flexible or rigid tubing.
o 3/8" NPT (National Pipe Thread): Male threaded end for secure, leak-resistant connections.
· Material Options:
o Plastic (e.g., PBT or nylon): Lightweight, cost-effective, and corrosion-resistant.
o Brass: Durable, handles higher pressures and temperatures.
o Stainless Steel: For high-pressure or corrosive environments.
· Pressure Rating: Typically supports 150-300 PSI (varies by material and manufacturer).
· Temperature Range:
o Plastic: 32°F to 140°F.
o Metal: Wider range, depending on the specific alloy used.
SKU: 1869X6X6S
