The Male 90° Elbow Quick Connect (1/2" Tube x 3/8" NPT) is a highly useful fitting that enables efficient directional changes and quick, secure connections in pneumatic and fluid systems.
Key Specifications:
· Configuration:
o 90° Elbow: Provides a right-angle connection to redirect flow in tight spaces.
o Quick Connect: Allows tool-free installation, making it quick and easy to connect tubing.
· Connections:
o 1/2" Tube: Push-to-connect for flexible or rigid tubing, ensuring a secure and fast connection.
o 3/8" NPT (Male Pipe Thread): Male tapered pipe thread for a strong, leak-resistant connection.
· Material Options:
o Plastic (e.g., PBT or Nylon): Lightweight and corrosion-resistant, ideal for lower pressure applications.
o Brass: Suitable for higher-pressure applications and more durable in varying temperature conditions.
o Stainless Steel: Offers high resistance to corrosion and is ideal for more demanding environments.
· Pressure Rating: Typically supports 150-300 PSI, depending on the material and manufacturer.
· Temperature Range:
o Plastic: 32°F to 140°F.
o Metal: Can handle broader temperature ranges depending on material type.
SKU: 1869X8S
