The Male 90° Elbow Quick Connect (1/2" Tube x 1/4" NPT) is a fitting designed for efficient and secure connections, providing a right-angle turn in pneumatic and fluid systems.
Key Specifications:
· Configuration:
o 90° Elbow: Redirects flow at a right angle, ideal for tight spaces.
o Quick Connect: Ensures easy, tool-free tubing connection.
· Connections:
o 1/2" Tube: Push-to-connect fitting for reliable and quick attachment of tubing.
o 1/4" NPT (Male Pipe Thread): Standard tapered threading for secure and leak-resistant connections.
· Material Options:
o Plastic (e.g., PBT or Nylon): Lightweight, corrosion-resistant, and economical.
o Brass: Durable and suitable for higher pressure and temperature conditions.
o Stainless Steel: Corrosion-resistant and ideal for heavy-duty or food-grade applications.
· Pressure Rating: Generally supports 150-300 PSI (depending on material).
· Temperature Range:
o Plastic: 32°F to 140°F.
o Metal: Broader range, depending on material properties.
SKU: 1869X8X4S
