The "Elbow 90 Deg PC 6Mm X 1/4"" NPT Swive" describes a specific type of elbow fitting used in piping or tubing systems. Here's a detailed explanation of its components and typical applications:
Component Breakdown Elbow 90 Deg Pc 6Mm X 1/4"" Npt Swive :
1. Elbow 90 Deg:
o Indicates a 90-degree angled fitting used to change the direction of flow.
2. PC (Push-to-Connect):
o A mechanism allowing quick and tool-free connection for tubing.
o Often used in pneumatic or low-pressure systems.
3. 6mm:
o Refers to the outer diameter (OD) of the tubing that fits into the push-to-connect end.
4. 1/4"" NPT:
o Refers to a 1/4-inch National Pipe Thread (NPT) connection on the other side of the fitting.
o This threaded connection is standardized for secure, leak-proof sealing.
5. Swivel:
o The threaded NPT end can rotate, allowing easy installation and positioning without twisting the tubing or pipe.
SKU: M1869X6X4S
